Descrição
COMPATIBILIDADE:
100% nos seguintes veículos:
Mercedes-Benz W219 W463 E-Class W211 (2000-2008)
CLS W219
G Class W463
CLK W209 E200/E220/E240/E270/E280
Nota: Em alguns modelos verificou-se incompatibilidade com os comandos do volante, isso deve-se às especificações do sistema original da viatura e não a uma avaria da unidade.
Para viaturas com cabo de fibra óptica e unidade de rádio na mala, irá necessitar de uma extensão de 5 mts para concluir a instalação. Contacte-nos ou adicione simplesmente 89 € ao pagamento para que lhe seja enviada essa extensão.
- Sistema operativo Android 12.0
- CPU: Rockchip 3188 Quad-Core 2GHZ 32GB
- Ecrã capacitativo HD 1024x600
- Airplay & Miracast - Espelha o ecrã do telefone para a unidade central:
* Android 4.2 ou superior. IPhone iOS 7.0 e acima)
- Disco rígido 32GB
- Memória 2G DDR3 RAM
- Vídeo 1080p HD
- Sistema mãos livres inteligente Bluetooth, com o visualização da lista telefónica e reprodução música Bluetooth (A2DP).
- A mais alta configuração de rádio com RDS, TDA7706 Chipset ( Philips)
- Suporte HD de jogos 2D e 3D
- Camera dianteira e traseira da câmera podem trabalhar em conjunto
- Suporte SD / MMC / SDHC Portas SD, SDHC Suporta Max 64G, HDD
-
Instalation Notes:
OPTIONAL: For mercedes benz with original GPS or fiber optic cables to amplifier in the trunk: You should use our 6m long power cable B5 which is optional (Select in dropdown), just run the long cable B5 from the back of the navigation DVD unit to the rear plug which is connected with amplfier and speakers under the trunk, so you need to unplug the existing amplifier with speakers, and then plug the other end of the long cable with speakers and by-pass the existing amplfier. P.S. Our DVD head unit has amplifier built-in.
Capacitive HD1024*600. GPS, 1080P video, Front and Rear Camera (optional). External Mic Included. Europe Maps as a gift (Another places ask us). DSP
Options: Front DVR Camera with MicroSD 8GB, touch screen operation. Rear Camera Universal. DVB-T Box with 2 active antenna, USB DAB+ Receiver
We send from European Union
Android 7.1, Quadcore 4x1.6Ghz. 16 GB ROM, 2GB RAM. 4x45W. SD/USB, WIFI, BLUETOOTH and much more
Specifications Platform Android S190 | ||||
---|---|---|---|---|
|
||||
Main component configuration | ||||
CPU | Intel & RK, Cortex-A9 8 core processor | |||
Frecuency | up to 1.6GHz | |||
Memory | Flash | eMMC 16GB | ||
RAM | DDR3 2GB | |||
MCU | 32 mainstream ARM controller、STM32F091VCTx QFP100 | |||
Touch Panel | Capacitive touch panel (G+G, Support 5 points touch) | |||
Radio | ST7786M/NXP6686 | |||
DVD Loader | Corepine 860MC | |||
DVD Decoder | SPHE8288 | |||
Audio Processor | Rohm BD3702 | |||
Operating System | Android 7.1 | |||
Main Functions | ||||
Display Screen | Dimensions | 5~13 inch depend of model | ||
Display Resolution | 800 * 480, 1024 * 600, 1024 * 768. Maximum support HD 1080p | |||
Display Interface | TTL LVDS | |||
Color | 16bit 24bit | |||
Radio | AM / FM | Sí | ||
RDS | Sí | |||
Digital DAB+ Radio | Optional | |||
Bluetooth | Bluetooth Phone | Yes, with internal and external mic (included) | ||
A2DP | Yes (BT music APK can enter from main unit) | |||
Protocol | BT 4.0, HFP / HSP, A2DP, AVRCP, Phone book download | |||
Navigation | GPS | Yes | ||
GLONASS | Yes | |||
Television | External TV box | Optional, with touch screen control (DVB-T Mpeg4 or DVB-T2) | ||
Audio Player | Support Media Type | APE, FLAC, MP3, WMA, WAV, OGG, etc. | ||
Video Player | Support Media Type | AVI, RM, RMVB, WMV, ASF, FLV, DAT, MPG, MP4, VOB, 3GP, etc., HD 1080P RMVB, etc. | ||
Image Browser | Support Media Type | JPEG, BMP, GIF, support image preview, zoom, etc | ||
DVR | USB Interface | Support optional DVR front camera | ||
Mirror Link | Android mobile phone | Yes (The phone need to be Android 4.2 or higher) | ||
Apple phone IOS | Yes (iOS 7.0 or higher) | |||
TPMS | Optional | |||
OBD Display | OBD2 optional | |||
Audio Processing | Volume, Bass, Treble, Balance, Fader, Loudness, EQ | |||
USB | Support 4 ways USB, up to 64GB | Compatible USB1.0, USB2.0. Support audio, image, video playback | ||
SD | 2 MicroSD, up to 64 GB | Support SD 3.0, SDHC. Audio, image, video Playback | ||
WIFI | Wifi | Yes, Built-In; protocol 802.11 b / g / n | ||
Automatic brightness control | ILL Detection | Yes | ||
Rear Camera (optional) | Switch to reverse mode | Under 1 second | ||
BACKING track | Support | |||
Another parameters | ||||
Working Temperature | -20ºC a 70ºC | |||
Working Humidity | 5% ~ 95% | |||
Operating Voltage Range | 9V ~ 16V | |||
Sleep Current | max. 9mA | |||
Deep standby current | max. 3mA | |||
System cold start time | Within 30 seconds (from deep standby to normal) | |||
Fast System Start | 3 seconds (from normal standby) |
FEATURES
|
---|
Prestigious manufacturer with many years in the market, devices are incomparable in terms of quality of manufacture.
And this series has many important advantages: more RAM, durable materials, greater stability and power. |
GPS, Radio AM/FM with RDS (Stations name OK), Bluetooth external mic included, Google Play, USB, SD, Mirrorlink, WiFi Built-In, EqualizerThese are just some of the functions we can find on this unit. Multilanguage: Spanish, English, French, German, Italian, Polish, Hungarian, etc.This is android! Supports all Android software (Compatible with the android version of the product) Support all maps for Android (Compatible with the android version of the product). Nonetheless we include as gift, Europe maps. ![]() |
Smart menu, simple and clear access to functions, quick navigation |
Rockchip PX3 / RK3188 4-core processor in Cortex-A9 architecture, 2 GB DDR3 RAM and 16 GB internal memory.The Android 7.1 operating system Nougat. Faster, more stable, more fluid.GPS with gift maps (Europe, for other areas ask us), Wi-Fi (you can connect it to your shared 3G / 4G mobile phone connection or WiFi network, Bluetooth, microphone included![]() |
The radio is equipped with a capacitive multi-touch HD display. Resolution: 1024 * 600 HDThe sensible screen responds even to a light touch and recognizes up to 5 touchs at a time.You can change the wallpaper, widgets.
|
Mirrorlink: To project your phone / tablet into the unit and share files (music, video ...)
|
CD / DVD Free Region, Disc playback compatibility: DVD-R / -RW, DVD + R / + RW, Video CD, SVCD, Picture CD, CD-R, CD-RW. Playback Compatibility: MP3 / WMA / ASF / MP4 / AVI / DAT / DIVX / MPEG / SVCD / VCD / XVID
|
1080P HD
For digital TV you need to add the option "TDT BOX Mpeg4 Touch"
|
DVR recorder front camera optional with touch screen control
|
Rear view camera input (optional camera with reference lines)Automatic shift to backview when reverse gear.![]() |
Bluetooth 4.0:
|
Music, Video, Picture, 2x USB Ports (Max. 64GB) and 2x microSD Slots. (Max 64GB), supports SDHCAlso music, video can listen through internet and Android applications. In addition to the CD / DVD.![]() |
![]() |
CanBus Incluided, steering wheel control ok |
